CASTinTACT® 3
|
|
|
|
|
|
|
|
|
|
|
|
CASTinTACT® 3
|
Cementitious concrete panels offer dimensional stability and compatibility to concrete; similar co-efficient of expansion as base. Superior strength, durability and abrasion resistance achieved with an engineered mix design.
Microsilica enhanced to increase compressive strength and reduce permeability to chloride ion intrusion; resists severe exposure to wet freeze thaw damage and de-icing chemicals.
Three dimensional reinforced with fibrillating monofilament fibers to increase flexural strength, ductility and toughness.
Panels are architectural finished to enhance concrete work. Full depth UV and weather proof integral colors provide long term visual contrast. Textured concrete finish for wet and dry slip resistance.
CASTinTACT® 3 panels are uniquely installed in a patented early entry-fast set method that takes 10 minutes. Panels are recessed flush to surface and bond to concrete base becoming a integral and permanent part of the walking surface. Because they are concrete, they offer long term durability, compatibility, similar coefficient of expansion as the concrete base, and easy to clean, maintain and repair.
Panel Dimensions
2’ x 2’ Panel
2.5’ x 2’ Panel
3’ x 2’ Panel
Panels recess to become an integral, permanent part of the walking surface.
|
|
|
|
|
|
|
Project Gallery
|
|
|
|
|
|
|
|
|
|
|
|
|
A Project Gallery is available to view finished installations of CASTinTACT® 3 concrete tactile warning panels.
|
|
|
|
|
|
|
|
|
|
- Cementitious concrete panels used for both new construction and retrofit.
- Easy to cut and core, uses on radiuses, around bollards, stairs, and vault boxes.
- Textured concrete finish for wet and dry slip resistance.
- High compressive and flexural strength, durable, tough and crack resistant.
- Compatible with concrete base, similar thermal co-efficient of expansion as base.
- Resistant to severe exposure, wet freeze thaw damage from de-icing chemicals.
- Panels become an integral and permanent part of the walking surface.
- Unique patented early fast-set installation method that takes 10 minutes.
- CASTinTACT® 3 panels do not float during installation. Panels stay where placed.
- Eliminates air pockets, voids, tripping hazards and ballast weight used during installation.
- Panels appearance improves with wear and age
- Easy to clean, maintain and repair.
|
|
|
|
|
|
|
|
|
|
|
CASTinTACT® 3 panels comply with ADAAG visual contrast requirements of light-on-dark or dark-on-light with inert synthetic iron oxide pigments meeting ASTM C979 - Standard Specification for Pigments for Integrally Colored Concrete.
Available in 4 standard colors:
- Salem Red
- Black
- White
- Yellow
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Installation
|
|
|
|
|
|
|
|
|
|
|
|
|
Recess concrete with INSTALaTACT®, then lock in CASTinTACT® 3 panels, install control joints and finish.
|
|
|
|
|
|
|
|
|
|
CASTinTACT® 3 is easy to cut and core drill.
Use on radiuses, around vaults, bollards and light standards.
|
|
|
|
|
|
|
|
|
|
CASTinTACT® 3 works great for creating blended transitions.
|
|
|
|
|
|
|
|
|
|
Ramp Type
- Tactile Ramp Cross Section
- Parallel Ramp Option 1
- Parallel Ramp to Crossing
- Parallel Ramp Option 3
- Perpendicular Ramp
- Perpendicular Ramp Option 3
- Perpendicular Radius Ramp
- Perpendicular Radius Ramp
- Perpendicular Radius Ramp Option 2
- Perpendicular to Curb
- Single Diagonal Ramp
- Radius Ramp (15’ Radius x 24 with setback)
- Radius Ramp (15’ Radius x 36 with setback)
|
|
|
|
|
|
|
|
|
|
|
- Versatile for all exterior applications
- Fast installation into fresh concrete
(typical fresh set curb ramp takes 10 minutes)
- Recess flush, becoming an integral part of the
walking surface, adding structural integrity.
- Panels remain flush with surface – no floating for
tripping hazards
- Proper control joints easily cut during early entry
(fresh set install, preventing cracking)
- Adaptive: Easy to cut and core drill with diamond blades on the job
- Drawings available in .DWG and .PDF formats online
- Installation pictures available online
- Contractor training available by local distributors
- Early Entry Installation
- Retrofit Installation
- Thin Set Installation
|
|
|
|
|
|
|
|
|
|
|
CASTinTACT® 3 PANELS ARE EARLY ENTRY-FRESH SET WITH INSTALaTACT® TOOL
- 2' x 4' Tool
- 3' x 4' Tool
|
Recess concrete with INSTALaTACT® tool, insert CASTinTACT® panel and finish level with concrete surface.
|
|
|
|
|
|
|
|
|
|
The CASTinTACT® Panel Caddy is an innovative patent pending tool designed to assist the contractor with CASTinTACT® panel installation.
- Easily lower panels into place!
- Increases efficiency!
- CASTinTACT® Panel stays secure during parging.
- Slide handle for locking and releasing panel during installation.
- Adjustable panel clip for different placement depths.
- Handle Bar used for steering caddy.
- Handle length is adjustable for user.
- 2 wheels allow easy maneuvering of the caddy.
|
|
|
|
|
|
|
|
|
|
|
When properly installed, CASTinTACT® 3 concrete tactile warning panels have low maintenance and provide an attractive finish.
- CASTinTACT® concrete panels are easily cleaned by pressure washing.
- Mild detergent washes and commercial concrete cleaners speed process.
- Cementitious panels can be repaired without replacing the entire ramp.
- Truncated domes are easy to core drill and replace.
|
|
|
|
|
|
|
|
|
|
|
Keep your ramps in compliance.
CASTinTACT® 3 cementitious concrete panels can be repaired fast and easy without replacing the entire ramp.
REPAIRaTACT™ tool with diamond bit for use
with gas or electric drill unit.
Place drill bit on dome to be repaired. Foot plate will line up on adjacent domes. Core through concrete panel into substrate approximately 2" and remove core.
Grout replacement plug with polymer modified repair mortar; colored to match panel. Foot plate can be used to help center and align.
|
|
|
|
|
|
|
